1 Core Low Voltage Cable YJV Copper XLPE Power Cable 0.6/1kV

YJV is a 0.6/1kV copper core power cable with XLPE insulation and a PVC sheath, suitable for fixed installations. It is widely used in building feeders, industrial power distribution, and infrastructure lines, trusted for its stable and reliable performance and ease of procurement.

YJV is a proven low-voltage power cable suitable for everyday power distribution work. It features reliable insulation, ease of installation by construction personnel, and a wide range of specifications to meet project requirements for predictable delivery and consistent quality.

YJV is one of the most commonly used low-voltage power cables for fixed installations. It typically uses stranded copper conductors to ensure high conductivity and stable terminations; the XLPE insulation provides excellent electrical performance; and the PVC outer sheath provides effective mechanical protection in conventional installation environments. YJV is widely used in feeders, sub-feeders, and distribution lines in commercial buildings, factories, utilities, and general infrastructure, especially suitable for situations where procurement teams require a full range of familiar models that are easy to accept.

Typical Rated Voltage:

0.6/1 kV

Typical System Applications:

Fixed wiring for low-voltage power distribution, feeder circuits, and equipment power supplies

Application Focus:

Fixed installation in cable trays, conduits, trunking, shafts, and protective wiring

• Main and branch feeders in residential and commercial buildings
• Power distribution circuits in factories, workshops, and production lines
• Power supply lines for pumps, HVAC equipment, and general factory utilities
• Cable trays in building distribution rooms and risers
• Low-voltage networks for utilities and infrastructure that accept standard PVC sheathing

• Outdoor wiring in cable trays, conduits, trunking, shafts, and protective wiring
• Not suitable for applications involving continuous movement, dragging, or high-frequency bending

• Stable performance for standard low-voltage power distribution. XLPE Insulation ensures reliable electrical performance for long-term fixed installations.
• High-efficiency copper conductors for power transmission. Copper conductors offer excellent conductivity and stable termination performance, suitable for common low-voltage feeder projects.
• Convenient procurement. Universal models and sizes allow for quick quotations, facilitating changeover planning for multi-stage projects.
• Equalized protection suitable for general environments. The PVC sheath effectively prevents abrasion and can withstand common field operations in standard installations.

Conductor:

Copper, stranded

Insulation:

Cross-linked polyethylene (XLPE)

Filler and Sheath:

As per structural standard requirements

Outer Sheath:

Polyvinyl chloride (PVC)

Armor:

None (Standard YJV; armored types specified separately)

Cable Type:

Low-voltage power cable for fixed installation

• Copper Conductor Stranding. The conductor stranding method is controlled to balance current carrying capacity, traction flexibility, and termination reliability.
• Cross-linked Polyvinyl chloride (XLPE) Insulation Extrusion and Cross-linking. XLPE is extruded and cross-linked to form a robust insulation layer suitable for low-voltage distribution.
• Core Marking and Wiring. The cores are assembled using a controlled geometry to maintain roundness and reduce traction friction in conduits and cable trays.
• Polyvinyl chloride (PVC) Sheath Extrusion and Marking. The PVC sheath protects the cable during installation and use, and is subsequently clearly printed for easy traceability.
• Routine Inspections. Typical inspection items include conductor resistance, insulation thickness, dimensional inspection, necessary spark/voltage testing, and sheath integrity.

• 1C Single-core Feeder (Installed according to local standards)
• 2C Single-phase Circuit
• 3C Three-phase Circuit without Neutral (Depending on Design)
• 4C Three-phase Feeder with Neutral (Common)
• 5C Three-phase Feeder with Neutral and Protection Circuit (Depending on Design)

• 1.5
• 2.5
• 4
• 6
• 10
• 16
• 25
• 35
• 50
• 70
• 95
• 120
• 150
• 185
• 240
• 300

• 3C x 4
• 3C x 6
• 3C x 10
• 4C x 6
• 4C x 10
• 4C x 16
• 4C x 25
• 4C x 35
• 4C x 50
• 5C x 10
• 5C x 16
• 5C x 25
• 1 core x 70
• 1 core x 95
• 1 core x 120
• 1 core x 150

1. Confirm your system voltage rating requirements (typically 0.6/1kV).
2. Select the number of cores based on the circuit design and neutral/protection circuit scheme.
3. Select the cross-sectional area based on load current, distance, grouping, ambient temperature, and permissible voltage drop.
4. Confirm the installation route and mechanical risks; select armored or low-smoke halogen-free (LSZH) models only if required by the Bill of Quantities (BOQ).
5. Define the reel length and splicing scheme to reduce field splicing and speed up commissioning.
